Relais De Contrôle Vérifiant Que Le Régime Est Atteint Et Non Dépassé 24 à 240 V DC/AC N/A Siemens 3UG46511AW30

Caractéristiques

• Type de produit: Relais
• Longueur: 86

Informations techniques

Retard à l’enclenchement : 1 – 900 s

Informations techniques

Contenu: 1 pc(s)
Dimensions: (L x l x H) 86 x 22.5 x 110 mm
Dimensions produit, hauteur: 110 mm
Dimensions produit, largeur: 22.5 mm
Fonctions (relais): Avertissement d’une vitesse de rotation trop faible, Avertissement d’une vitesse de rotation trop élevée
Longueur: 86 mm
Tension de fonctionnement (gamme): 24, 24 – 240, 240 V/DC, V/AC
Tension de fonctionnement max.: 240 V/DC, 240 V/AC
Tension de fonctionnement min.: 24 V/DC, 24 V/AC
Type de produit: Relais de surveillance

Digital monitoring relay speed monitoring from 0.1 to 2200 rpm

Digital monitoring relay Speed monitoring from 0.1 to 2200 rpm Overshoot and undershoot 24 to 240 V AC/DC 50 to 60 Hz DC and AC ON delay 1 to 900 s Tripping delay 0.1 to 99.9 s Hysteresis 0.1 to 99 rpm 1 change-over contact with or without fault buffer screw terminal Successor product for 3UG3051 Speed monitoring relay with digital setting SIRIUS 3UG4 for speed monitoring for overshooting and undershooting, e.g. in the event of slip or tear in a belt drive, also suitable for slowly rotating motors. Worldwide use thanks to wide voltage supply range and international certificates. Fast commissioning possible, thanks to menu-guided parameterization and actual value display for limit value determination. The devices features a permanent display of actual value and fault type. 2- or 3-wire sensors and sensors with a mechanical switching output or semiconductor output can be connected Auxiliary voltage for sensor is integrated. Device replacement possible without rewiring, thanks to removable terminals Reliable system diagnostics, thanks to unambiguous error messages on the display and connectable fault memory. In addition to screw terminals, all the devices are also available with spring-type terminals for fast, maintenance-free and vibration-proof connection. They are optionally available with IO-Link. The comprehensive range of accessories, such as unit labeling plates, push-in lugs and cover caps, is standardized for all relays. SIRIUS relays – one range for every application.

Points forts

• Siemens 3UG46511AW30
• Tension de fonctionnement (détails): 24 à 240 V DC/AC
• Dimensions: (L x l x H) 86 x 22.5 x 110 mm
