API – Module électronique Siemens 6ES7132-4BF00-0AA0 6ES71324BF000AA0 24 V/DC 1 Pc(s)

Caractéristiques

• Type de produit: Adaptateur
• Tension: 24
• Longueur: 52

Informations techniques

Module électronique pour et 200S pouvoir de coupure des sorties : 5 W.

Informations techniques

Contenu: 1 pc(s)
Dimensions: (L x l x H) 52 x 15 x 81 mm
Dimensions produit, hauteur: 81 mm
Dimensions produit, largeur: 15 mm
Indice de protection: IP20
Longueur: 52 mm
Modèle (général): Module électronique Standard
Nombre de canaux (détails): –
Nombre de sorties max.: 8
Nombre de sorties relais max.: 8
Poids: 40 g
Tension de fonctionnement: 24 V/DC
Tension de fonctionnement (gamme): 24 V/DC (max)
Tension de fonctionnement max.: 24 V/DC
Type de produit: API – Module électronique

Module Electronique Simatic Dp 1 St 8Da Siemens 6ES7132-4BF00-0AA0

Electronics module for ET 200S, 8 DO 24 V DC/0.5 A, 15 mm width, 1 unit per packing unit SIMATIC ET 200S is a modularly scalable, distributed I/O system that is specially designed for installation in small control boxes near the machine. The modules can either be plugged directly into an ET 200S IM with CPU functionality or connected to a central controller via PROFINET or PROFIBUS. SIMATIC ET 200S can be expanded with up to 64 I/O modules, which can be inserted in any combination. The system provides a comprehensive range of modules. Many modules are also available with a wide variety of characteristics, which considerably improve the scalability in regard to functionality and price. Thus, in addition to modules with standard functions (ST), modules with an extended range of functions and diagnostics (HF High Feature/ HS High Speed) are also available. The advantage of the ET 200S system is in its ease of application, such as through the capability of swapping modules and terminal boxes during operation. The availability and productivity of the machine are considerably increased due to the so-called hot swapping.

Points forts

• Siemens 6ES7132-4BF00-0AA0 6ES71324BF000AA0
• Contenu: 1 pc(s)
